Projector for outdoor installation on a façade/wall. Body in anodized aluminum with phospho-chromatised and polyester powder coating, bracket in stainless steel, tempered safety glass, moulded silicone gasket and stainless steel screws. With 1 direct 220-240V LUMENS “EDC 38C” COB LED. IP66 rating.
Product IMAGE
Technical drawing
| Product code | watt | light source | Beam angle | LUMENS | finish | Dimming | ||
|---|---|---|---|---|---|---|---|---|
| 101902.27.20.03.0 | 8W | 2700K | 20° | 380 |
RAL9005 |
ON/OFF | ||
| 101902.27.20.02.0 | 8W | 2700K | 20° | 380 |
RAL7016 |
ON/OFF | ||
| 101902.27.20.01.0 | 8W | 2700K | 20° | 380 |
RAL9006 |
ON/OFF | ||
| 101902.27.40.03.0 | 8W | 2700K | 40° | 371 |
RAL9005 |
ON/OFF | ||
| 101902.27.40.02.0 | 8W | 2700K | 40° | 371 |
RAL7016 |
ON/OFF | ||
| 101902.27.40.01.0 | 8W | 2700K | 40° | 371 |
RAL9006 |
ON/OFF | ||
| 101902.30.20.03.0 | 8W | 3000K | 20° | 400 |
RAL9005 |
ON/OFF | ||
| 101902.30.20.02.0 | 8W | 3000K | 20° | 400 |
RAL7016 |
ON/OFF | ||
| 101902.30.20.01.0 | 8W | 3000K | 20° | 400 |
RAL9006 |
ON/OFF | ||
| 101902.30.40.03.0 | 8W | 3000K | 40° | 390 |
RAL9005 |
ON/OFF | ||
| 101902.30.40.02.0 | 8W | 3000K | 40° | 390 |
RAL7016 |
ON/OFF | ||
| 101902.30.40.01.0 | 8W | 3000K | 40° | 390 |
RAL9006 |
ON/OFF | ||
| 101902.40.20.03.0 | 8W | 4000K | 20° | 410 |
RAL9005 |
ON/OFF | ||
| 101902.40.20.02.0 | 8W | 4000K | 20° | 410 |
RAL7016 |
ON/OFF | ||
| 101902.40.20.01.0 | 8W | 4000K | 20° | 410 |
RAL9006 |
ON/OFF | ||
| 101902.40.40.03.0 | 8W | 4000K | 40° | 400 |
RAL9005 |
ON/OFF | ||
| 101902.40.40.02.0 | 8W | 4000K | 40° | 400 |
RAL7016 |
ON/OFF | ||
| 101902.40.40.01.0 | 8W | 4000K | 40° | 400 |
RAL9006 |
ON/OFF | ||
| Product code | watt | light source | Beam angle | LUMENS | finish | Dimming | ||
|---|---|---|---|---|---|---|---|---|
| 101903.27.04.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 4° | 485 lm (@350mA) / 656 lm (@500mA) / 862 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.27.04.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 4° | 485 lm (@350mA) / 656 lm (@500mA) / 862 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.27.04.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 4° | 485 lm (@350mA) / 656 lm (@500mA) / 862 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.27.10.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 10° | 465 lm (@350mA) / 629 lm (@500mA) / 828 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.27.10.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 10° | 465 lm (@350mA) / 629 lm (@500mA) / 828 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.27.10.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 10° | 465 lm (@350mA) / 629 lm (@500mA) / 828 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.27.28.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 28° | 450 lm (@350mA) / 609 lm (@500mA) / 804 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.27.28.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 28° | 450 lm (@350mA) / 609 lm (@500mA) / 804 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.27.28.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 28° | 450 lm (@350mA) / 609 lm (@500mA) / 804 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.27.55.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 55° | 383 lm (@350mA) / 519 lm (@500mA) / 683 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.27.55.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 55° | 383 lm (@350mA) / 519 lm (@500mA) / 683 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.27.55.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 2700K | 55° | 383 lm (@350mA) / 519 lm (@500mA) / 683 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.30.04.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 4° | 510 lm (@350mA) / 690 lm (@500mA) / 907 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.30.04.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 4° | 510 lm (@350mA) / 690 lm (@500mA) / 907 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.30.04.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 4° | 510 lm (@350mA) / 690 lm (@500mA) / 907 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.30.10.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 10° | 489 lm (@350mA) / 662 lm (@500mA) / 872 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.30.10.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 10° | 489 lm (@350mA) / 662 lm (@500mA) / 872 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.30.10.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 10° | 489 lm (@350mA) / 662 lm (@500mA) / 872 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.30.28.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 28° | 474 lm (@350mA) / 642 lm (@500mA) / 846 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.30.28.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 28° | 474 lm (@350mA) / 642 lm (@500mA) / 846 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.30.28.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 28° | 474 lm (@350mA) / 642 lm (@500mA) / 846 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.30.55.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 55° | 403 lm (@350mA) / 546 lm (@500mA) / 719 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.30.55.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 55° | 403 lm (@350mA) / 546 lm (@500mA) / 719 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.30.55.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 3000K | 55° | 403 lm (@350mA) / 546 lm (@500mA) / 719 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.40.04.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 4° | 520 lm (@350mA) / 703 lm (@500mA) / 930 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.40.04.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 4° | 520 lm (@350mA) / 703 lm (@500mA) / 930 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.40.04.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 4° | 520 lm (@350mA) / 703 lm (@500mA) / 930 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.40.10.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 10° | 499 lm (@350mA) / 676 lm (@500mA) / 890 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.40.10.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 10° | 499 lm (@350mA) / 676 lm (@500mA) / 890 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.40.10.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 10° | 499 lm (@350mA) / 676 lm (@500mA) / 890 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.40.28.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 28° | 484 lm (@350mA) / 656 lm (@500mA) / 863 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.40.28.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 28° | 484 lm (@350mA) / 656 lm (@500mA) / 863 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.40.28.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 28° | 484 lm (@350mA) / 656 lm (@500mA) / 863 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| 101903.40.55.01.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 55° | 411 lm (@350mA) / 558 lm (@500mA) / 734 lm (@700mA) |
RAL9006 |
ON/OFF | ||
| 101903.40.55.02.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 55° | 411 lm (@350mA) / 558 lm (@500mA) / 734 lm (@700mA) |
RAL7016 |
ON/OFF | ||
| 101903.40.55.03.0 | 5W (@350mA) / 7W (@500mA) / 10W (@700mA) | 4000K | 55° | 411 lm (@350mA) / 558 lm (@500mA) / 734 lm (@700mA) |
RAL9005 |
ON/OFF | ||
| Product code | watt | light source | Beam angle | LUMENS | finish | Dimming | ||
|---|---|---|---|---|---|---|---|---|
| 101903.RW.12.01.D | 4.5W | RGBW | 12° | 160 |
RAL9006 |
DALI | ||
| 101903.RW.12.01.X | 4.5W | RGBW | 12° | 160 |
RAL9006 |
DMX | ||
| 101903.RW.12.02.D | 4.5W | RGBW | 12° | 160 |
RAL7016 |
DALI | ||
| 101903.RW.12.02.X | 4.5W | RGBW | 12° | 160 |
RAL7016 |
DMX | ||
| 101903.RW.12.03.D | 4.5W | RGBW | 12° | 160 |
RAL9005 |
DALI | ||
| 101903.RW.12.03.X | 4.5W | RGBW | 12° | 160 |
RAL9005 |
DMX | ||
| 101903.RW.25.01.D | 4.5W | RGBW | 25° | 152 |
RAL9006 |
DALI | ||
| 101903.RW.25.01.X | 4.5W | RGBW | 25° | 152 |
RAL9006 |
DMX | ||
| 101903.RW.25.02.D | 4.5W | RGBW | 25° | 152 |
RAL7016 |
DALI | ||
| 101903.RW.25.02.X | 4.5W | RGBW | 25° | 152 |
RAL7016 |
DMX | ||
| 101903.RW.25.03.D | 4.5W | RGBW | 25° | 152 |
RAL9005 |
DALI | ||
| 101903.RW.25.03.X | 4.5W | RGBW | 25° | 152 |
RAL9005 |
DMX | ||
| 101903.RW.35.01.D | 4.5W | RGBW | 35° | 145 |
RAL9006 |
DALI | ||
| 101903.RW.35.01.X | 4.5W | RGBW | 35° | 145 |
RAL9006 |
DMX | ||
| 101903.RW.35.02.D | 4.5W | RGBW | 35° | 145 |
RAL7016 |
DALI | ||
| 101903.RW.35.02.X | 4.5W | RGBW | 35° | 145 |
RAL7016 |
DMX | ||
| 101903.RW.35.03.D | 4.5W | RGBW | 35° | 145 |
RAL9005 |
DALI | ||
| 101903.RW.35.03.X | 4.5W | RGBW | 35° | 145 |
RAL9005 |
DMX | ||
