Projector for outdoor installation on a façade/wall. Body in anodized aluminum with phospho-chromatised and polyester powder coating, bracket in stainless steel, tempered safety glass, moulded silicone gasket and stainless steel screws. Constant voltage 24V DC remote driver needed. With 1 x XP-G3 CREE LED. IP66 rating.
Product IMAGE
Technical drawing
| Product code | watt | light source | Beam angle | LUMENS | finish | Dimming | ||
|---|---|---|---|---|---|---|---|---|
| 101901.27.10.03.0 | 3W | 2700K | 10° | 238 |
RAL9005 |
ON/OFF | ||
| 101901.27.10.02.0 | 3W | 2700K | 10° | 238 |
RAL7016 |
ON/OFF | ||
| 101901.27.10.01.0 | 3W | 2700K | 10° | 238 |
RAL9006 |
ON/OFF | ||
| 101901.27.30.03.0 | 3W | 2700K | 30° | 228 |
RAL9005 |
ON/OFF | ||
| 101901.27.30.02.0 | 3W | 2700K | 30° | 228 |
RAL7016 |
ON/OFF | ||
| 101901.27.30.01.0 | 3W | 2700K | 30° | 228 |
RAL9006 |
ON/OFF | ||
| 101901.27.45.03.0 | 3W | 2700K | 45° | 219 |
RAL9005 |
ON/OFF | ||
| 101901.27.45.02.0 | 3W | 2700K | 45° | 219 |
RAL7016 |
ON/OFF | ||
| 101901.27.45.01.0 | 3W | 2700K | 45° | 219 |
RAL9006 |
ON/OFF | ||
| 101901.30.10.03.0 | 3W | 3000K | 10° | 250 |
RAL9005 |
ON/OFF | ||
| 101901.30.10.02.0 | 3W | 3000K | 10° | 250 |
RAL7016 |
ON/OFF | ||
| 101901.30.10.01.0 | 3W | 3000K | 10° | 250 |
RAL9006 |
ON/OFF | ||
| 101901.30.30.03.0 | 3W | 3000K | 30° | 240 |
RAL9005 |
ON/OFF | ||
| 101901.30.30.02.0 | 3W | 3000K | 30° | 240 |
RAL7016 |
ON/OFF | ||
| 101901.30.30.01.0 | 3W | 3000K | 30° | 240 |
RAL9006 |
ON/OFF | ||
| 101901.30.45.03.0 | 3W | 3000K | 45° | 230 |
RAL9005 |
ON/OFF | ||
| 101901.30.45.02.0 | 3W | 3000K | 45° | 230 |
RAL7016 |
ON/OFF | ||
| 101901.30.45.01.0 | 3W | 3000K | 45° | 230 |
RAL9006 |
ON/OFF | ||
| 101901.40.10.03.0 | 3W | 4000K | 10° | 270 |
RAL9005 |
ON/OFF | ||
| 101901.40.10.02.0 | 3W | 4000K | 10° | 270 |
RAL7016 |
ON/OFF | ||
| 101901.40.10.01.0 | 3W | 4000K | 10° | 270 |
RAL9006 |
ON/OFF | ||
| 101901.40.30.03.0 | 3W | 4000K | 30° | 260 |
RAL9005 |
ON/OFF | ||
| 101901.40.30.02.0 | 3W | 4000K | 30° | 260 |
RAL7016 |
ON/OFF | ||
| 101901.40.30.01.0 | 3W | 4000K | 30° | 260 |
RAL9006 |
ON/OFF | ||
| 101901.40.45.03.0 | 3W | 4000K | 45° | 250 |
RAL9005 |
ON/OFF | ||
| 101901.40.45.02.0 | 3W | 4000K | 45° | 250 |
RAL7016 |
ON/OFF | ||
| 101901.40.45.01.0 | 3W | 4000K | 45° | 250 |
RAL9006 |
ON/OFF | ||
